型號Model? MMD3000
最大磨削長度Max working length 3000mm
最大磨削寬度Max cutting width 200mm
砂輪轉速Wheel rotation rate 1400r/min
砂輪直徑Wheel diameter 200-250mm
裝機總功率Total power 6.47kw
磨削刀板角度Tilting angle of saw blade 0-45°
電磁吸盤調整角度Tilting angle of magnetic chuck 前90°后90°
外形尺寸Overall dimensions 5300*1250*1300mm
凈重Net weight 2900kg
